BRASS/COPPER MODEL - 2 Specification
| PART NUMBER | SUITBALE | MATERIAL | MODEL - 2 | |||||
|---|---|---|---|---|---|---|---|---|
| L | W | T | P | D1 | D2 | |||
| TAE/2011 | M10 | BRASS/COPPER | 69 | 21.3 | 1.5 | 39.7 | 11.7 X 15.8 | 11.7 X 15.8 |
| TAE/2012 | M8 | BRASS/COPPER | 54 | 18 | 2 | 36 | 8.4 X 9.5 | 8.4 X 9.5 |
| TAE/2013 | M6 | BRASS/COPPER | 42.5 | 12 | 1 | 20.5 | 7.3 X 12 | 7.3 X 12 |
| TAE/2014 | M6 | BRASS/COPPER | 32 | 11 | 0.5 | 16 | 6.3 X 9 | 6.3 X 9 |
| TAE/2015 | M5 | BRASS/COPPER | 32.4 | 11 | 0.6 | 17.4 | 5.4 X 5.8 | 5.4 X 5.8 |
| TAE/2016 | M4 | BRASS/COPPER | 27 | 9 | 0.7 | 15.9 | 4.4 X 5.4 | 4.4 X 5.4 |
Technical Drawing
