BRASS/COPPER MODEL - 4 Specification
| PART NUMBER | SUITBALE | MATERIAL | MODEL - 4 | |||||
|---|---|---|---|---|---|---|---|---|
| L | W | T | P | D1 | D2 | |||
| TAE/2025 | M6 | BRASS/COPPER | 42 | 12 | 0.6 | 26.9 | 7 X 10.4 | 7 X 10.4 |
| TAE/2026 | M5 | BRASS/COPPER | 32.5 | 9.5 | 0.5 | 20.2 | 5.5 X 8.2 | 5.5 X 8.2 |
| TAE/2027 | M4 | BRASS/COPPER | 25.3 | 8.4 | 0.5 | 14.5 | 4.2 X 6.5 | 4.2 X 6.5 |
Technical Drawing
